Anypack HD Heavy‑Duty
Triple‑Wall Boxmaker

ANypack boxmaker Logo

The Anypack HD is a purpose‑built heavy‑duty corrugated boxmaking machine designed for the toughest materials — including AAA‑flute triple wall up to 16mm thick. Built for industrial packaging producers, it delivers precision, reliability, and world‑class flexibility in a single compact system

Triple Wall & Heavy Duty Corrugated Box Production

Looking for a machine that can convert the toughest corrugated grades, including triple wall and heavy-duty board? The Anypack HD from Boxmaker.Pro is purpose-built for industrial packaging specialists who need reliable, flexible, and precise production of large, robust boxes. Ideal for export, logistics, e-commerce, and manufacturing, the HD model is engineered to handle the most demanding applications.


​

Handles the Heaviest Corrugated Grades

  • Converts AAA flute up to 16mm for extreme‑strength packaging requirements.

  • Ideal for export, logistics, e‑commerce and industrial box production.

​

High‑Precision Boxmaking

  • Male & female creasing wheels for crack‑free, accurate folds.

  • Offset creasing prevents material stress on thick stock.

  • Driven line cuts ensure perfect trimming quality.

​

Integrated Production in One Pass

  • Slitting, slotting, creasing, scoring, trimming and die‑cutting — all inline.

  • Inline gluing system for fast, seamless, high‑strength box assembly.

​

Heavy‑Duty Construction

  • Glue flap crushing roller for secure flap bonding.

  • Designed for large, robust box formats

​

Fast Changeovers & High Productivity

  • HD changeover time: 5–15 seconds — ideal for both short runs and continuous production.

  • Vacuum lead‑edge feeder allows single‑operator production.

​

Flexible Box Designs

  • Supports full range of FEFCO codes and custom styles.

​

Warranty & ROI

  • Includes a 12‑month parts warranty and is engineered for maximum efficiency and waste reduction.

Key Features for Heavy Duty & Triple Wall Boxmaking

Technical Specifications

Feature
Specification
Corrugated Capability
Handles single wall, double wall, and triple wall. Converts AAA flute up to 16mm.
Corrugated Weight
Supports material thickness/density up to 2400 g/m² (HD‑class capability).
Inline Operations
Slitting, slotting, creasing, scoring, trimming, and die‑cutting in a single pass.
Inline Gluing
Integrated inline gluing system for seamless, high‑strength assembly.
Creasing System
Male & female creasing plus offset creasing for thick corrugated grades.
Glue Flap Crushing
Heavy‑duty glue flap crushing roller for strong, tight flap bonding.
Feeding System
Vacuum lead‑edge feeder for accurate feeding. Full Pallet Feeder also available
Supported Box Styles
100+ FEFCO box styles plus custom designs.
Changeover Time
5–15 seconds on HD versions. ,
Production Rate
Typically 360–550 boxes per hour for HD‑range machines.
Max Board Size
Up to 2500–3000mm width with unlimited length (HD‑range capability).
Min Board Size
Minimum 400mm (W) x 700mm (L) for HD models.
Warranty
12‑month parts warranty.
Page 1 of 1

AQ 1 — What materials can the Anypack HD convert?

The Anypack HD is designed for heavy‑duty applications and can convert AAA flute triple‑wall corrugated up to 16mm, as well as single‑ and double‑wall grades.

​

FAQ 2 — How fast is changeover on the Anypack HD?

The HD model achieves rapid 5–15 second changeovers, making it ideal for both short‑run and continuous production.

​

FAQ 3 — What box styles can the machine produce?

It supports over 100 FEFCO box styles plus custom formats, suitable for export, e‑commerce, manufacturing, and industrial applications.

​

FAQ 4 — Does the Anypack HD include gluing features?

Yes — it includes an inline gluing system and a glue‑flap crushing roller for strong, secure flap bonding.

​

FAQ 5 — Is the Anypack HD suitable for large-format sheets?

Yes. HD‑range machines handle board widths up to 3000mm with unlimited length (based on the wider Anypack HD specification range).

​

FAQ 6 — What warranty is included?

The Anypack HD comes with a 12‑month parts warranty as standard.

​

FAQ 7 — Can one operator run the machine?

Yes — the vacuum lead‑edge feeder allows consistent, reliable feeding of heavy sheets by a single operator.
